Twist On Wire Connector 22-14 AWG Pk100 BUCHANAN Miniature Connector

Description

Product Overview

The BUCHANAN Twist On Wire Connector 22-14 AWG (Pk100) is engineered for precision and durability in demanding industrial environments. Constructed from high‑quality copper alloy, each connector offers excellent conductivity while resisting corrosion and wear over prolonged use. The connector complies with UL 486C and CSA C2.2#188 standards, guaranteeing that it meets rigorous safety and performance criteria for a wide range of applications.

Designed with a miniature cylindrical form factor, the connector measures just 0.32 inches in width and 0.33 inches in height, allowing it to be installed in confined spaces where larger connectors simply cannot fit. The twist‑on mechanism provides a secure, vibration‑resistant connection that can be quickly engaged or disengaged without the need for specialized tools, reducing downtime during maintenance or equipment upgrades.

Electrical specifications include a maximum voltage rating of 300 VAC and a current capacity suitable for typical industrial loads. The connector supports wire gauges from 22 AWG up to 16 AWG, making it versatile for both low‑current signal wiring and higher‑current power distribution. Its insulated housing ensures safe handling and protects against accidental short circuits.

Each pack contains 100 connectors, providing ample inventory for large projects or ongoing service needs. The product is sourced from Canada, reflecting BUCHANAN’s commitment to high manufacturing standards and consistent quality control throughout the supply chain.

Usage

These connectors excel in a variety of industrial settings, including manufacturing plants, automation systems, and heavy‑duty machinery. They are ideal for wiring control panels, motor starters, and sensor arrays where space constraints demand a compact solution. The twist‑on design also makes them suitable for field repairs, allowing technicians to secure connections quickly and reliably even in challenging locations.

In addition to traditional industrial applications, the connector is well‑suited for renewable energy installations such as solar inverters and wind turbine control units, where robust, weather‑resistant connections are essential. Its ability to handle both 22 AWG and 16 AWG stranded wires provides flexibility for power and communication lines within the same system.</n

For maintenance personnel, the connector’s tool‑free installation reduces the risk of stripped wires or damaged terminals, enhancing overall system reliability. Its compact size also facilitates routing through conduit, cable trays, and tight junction boxes without compromising performance.

Why Choose Us

Choosing BUCHANAN means selecting a brand with decades of experience in electrical components. Our connectors undergo rigorous testing for tensile strength, electrical resistance, and environmental durability, ensuring they perform consistently under temperature extremes and mechanical stress.

We stand behind every product with a comprehensive quality assurance program that includes batch testing and traceability. Should any issue arise, our dedicated technical support team is available to provide guidance, troubleshooting, and replacement options, reinforcing our commitment to customer satisfaction.

Our manufacturing facilities employ advanced extrusion and plating techniques that result in a uniform copper alloy composition, delivering superior conductivity and reduced voltage drop. The insulated housing is formulated to resist oil, chemicals, and UV exposure, extending the connector’s service life in harsh industrial environments.

By offering the Twist On Wire Connector in a convenient pack of 100, we help you streamline inventory management and reduce per‑unit costs, making it a cost‑effective choice for large‑scale projects and ongoing maintenance programs.

Key Features

• Compact miniature cylindrical design fits into tight spaces, simplifying installation in crowded panels.
• Twist‑on mechanism provides a secure, tool‑free connection that resists vibration and loosening.
• Supports 22‑16 AWG stranded wires, offering flexibility for both signal and power applications.
• Rated for 300 VAC with UL 486C and CSA C2.2#188 compliance, ensuring safety and reliability.
• Backed by BUCHANAN technical support and a robust warranty for peace of mind.

FAQ

What wire sizes can this connector accommodate?

The connector is designed for stranded wires ranging from 22 AWG up to 16 AWG, allowing it to be used for both low‑current signal wiring and higher‑current power distribution.

Is the connector suitable for outdoor or harsh environments?

Yes. The insulated housing is formulated to resist oil, chemicals, and UV exposure, making it appropriate for outdoor installations and environments with aggressive contaminants.

How does the twist‑on mechanism compare to crimp or solder connections?

The twist‑on design offers a fast, tool‑free installation while providing a secure, vibration‑resistant connection. Unlike crimp or solder methods, it reduces the risk of wire damage and allows for easy re‑termination if needed.

Can I use this connector in high‑current applications?

While the connector is rated for 300 VAC, it is intended for typical industrial loads. For high‑current applications exceeding the standard rating, consult the product specifications or contact BUCHANAN technical support for guidance.

What warranty or support does BUCHANAN provide?

BUCHANAN offers a comprehensive warranty covering manufacturing defects and provides access to a dedicated technical support team to assist with installation, troubleshooting, and replacement inquiries.

}
