Amphenol PT06E-8-4S Circular Socket Bayonet 8 Shell 4 Contact

Description

Product Overview

The Amphenol PT06E-8-4S circular connector socket is engineered for precision and durability in the most demanding industrial settings. Constructed from high‑grade alloyed steel, the socket provides excellent resistance to corrosion, vibration, and temperature extremes, ensuring a long service life even when exposed to harsh chemicals or moisture. The bayonet coupling mechanism offers a quick, secure lock‑in that prevents accidental disengagement, while the solder termination option allows for a robust, low‑resistance electrical connection that meets stringent IEC standards. With an 8‑shell housing and four carefully positioned contacts, the design balances compact size—measuring just 2 × 0.5 × 0.5 inches—with the ability to handle substantial current loads, making it suitable for a wide range of power and signal applications. The socket’s straight plug configuration simplifies installation on printed circuit boards or panel mounts, and its compatibility with a family of matching plugs (including part numbers 71‑570121‑04P, PT01E‑8‑4P, PT01E‑8‑4P(SR), and PT02E‑8‑4P) provides flexibility for system designers. Detailed specifications such as a 5.6‑ounce weight, NSN 5935‑00‑481‑1510, and a proven track record since its first release in April 2014 underscore the product’s reliability and market acceptance.

Usage

Designed for industrial electrical, automation, and control system environments, the PT06E-8-4S socket excels in applications where space is limited but performance cannot be compromised. It is ideal for use in machinery control panels, robotic arms, conveyor systems, and heavy‑duty power distribution units where secure, repeatable connections are critical. The bayonet coupling ensures a positive lock that can be quickly engaged or disengaged by technicians without the need for tools, reducing downtime during maintenance or equipment upgrades. Its solder termination capability makes it a preferred choice for high‑frequency signal transmission, where low‑impedance pathways are essential to maintain signal integrity. The socket also performs well in outdoor installations, such as oil‑field equipment or marine applications, thanks to its robust sealing and resistance to environmental contaminants. Engineers often select this connector for custom wiring harnesses that require a balance of mechanical strength and electrical performance, especially when integrating sensors, actuators, or safety devices that demand reliable interconnects.

Why Choose Us

Choosing the Amphenol PT06E-8-4S means partnering with a brand that has over 80 years of experience delivering high‑quality connectivity solutions worldwide. Each socket undergoes rigorous testing for mechanical endurance, electrical continuity, and environmental sealing, guaranteeing compliance with international standards such as UL, IEC, and RoHS. Our manufacturing process incorporates precision stamping and automated assembly lines that minimize variability, resulting in consistent performance across every unit. In addition to the superior material selection, we provide comprehensive documentation, including detailed wiring diagrams, installation guides, and 3‑D CAD models, to accelerate product integration and reduce engineering effort. Our dedicated technical support team is available to assist with custom specifications, troubleshooting, and design optimization, ensuring that you receive a solution that fits your exact needs. With a proven track record reflected in a #21 ranking within the Miniature Cylindrical Connectors category on major e‑commerce platforms, the PT06E-8-4S has earned the trust of OEMs and system integrators alike. We also stand behind our product with a robust warranty and a responsive after‑sales service that addresses any concerns promptly.

Key Features

• Robust bayonet coupling provides a secure, tool‑free lock that resists accidental disengagement.
• Solder termination ensures low‑resistance, high‑reliability electrical connections for demanding circuits.
• Compact 8‑shell, 4‑contact design fits tight spaces while delivering strong current‑carrying capability.
• High‑grade alloyed steel construction offers superior corrosion and vibration resistance for harsh environments.
• Dedicated technical support and comprehensive documentation simplify integration and guarantee long‑term satisfaction.

FAQ

What types of cables can be used with the PT06E-8-4S socket?

The socket is compatible with standard insulated copper conductors ranging from 20 AWG to 24 AWG. For optimal performance, use cables with a rated voltage that matches or exceeds the connector’s specifications and ensure proper stripping length before soldering.

Is the socket rated for high‑temperature applications?

Yes, the PT06E-8-4S is designed to operate reliably in temperatures from -40 °C to +85 °C, making it suitable for both indoor and outdoor industrial environments where temperature fluctuations are common.

Can the socket be used in a waterproof assembly?

When combined with a compatible waterproof plug and appropriate sealing gaskets, the PT06E-8-4S can achieve an IP67 rating, protecting the connection from dust and temporary immersion in water.

What is the recommended torque for tightening the soldered connections?

For optimal solder joint integrity, apply a torque of 0.5 Nm (4.4 in‑lb) using a calibrated torque screwdriver. This ensures a solid mechanical bond without damaging the contacts.

How does the bayonet coupling compare to a threaded coupling?

Bayonet coupling offers faster engagement and disengagement than threaded types, reducing installation time while still providing a secure lock. It also minimizes the risk of cross‑threading and is less susceptible to loosening under vibration.
